电源电压(v/Hz)voltage |
AC220/50 |
真空泵电机功率(W)Motor Power |
1000 |
热封功率(W)Sealing Power |
1000 |
真空室zui低绝对压强(Kpa)Ultimate Vacuum Pressure |
1 |
每室热封条数(pcs)No.of Sealing Bars for Each Chamber |
2 |
真空室内尺寸(LxWxH)(mm)Chamber Dimension |
630*630*100 |
热封条长度(mm)Sealing Length |
400/500/600 |
热封宽度(mm)Sealing Width |
10 |
真空泵排气量(m³/h)Vacuum Pump Rate |
20 |
真空室材质Material for Vacuum Chamber |
不锈钢Stainless steel 201 |
外形尺寸(LxWxH)(mm)Dimension |
760*750*980 |
净重(kg)Net Weight |
111 |
两条封口之间的中心距离(mm)The center distance between two sealing bars |
540 |
|
|
